| Product Line | Suspension |
| Category Name | Chassis & Suspension |
| Part Type | Rigid Torque Rod |
| Alternate Part Name | Torque Rod, Torque Rod Assy, Torque Arm Rigid, Torque Arm with Bushings |
| OEM Part Number | 6813266316 |
| Applicable Bushing | F184208 |
| Application Type | Semi-Trucks, Heavy Duty Trucks |
| Bolt Hole Diameter | 5/8 in. |
| Mounting Position | Front Axle Suspension |
| Torque Rod Style | Rigid |
| Material | Forged Steel |
| Bushing Orientation Angle – End 1 | 90 deg. |
| Bushing Orientation Angle – End 2 | 35 deg. |
| Bushing Type | Straddle/Bar Pin |
| Center Bar Outside Diameter (O.D.) | 1-9/16 in. |
| Distance Between Bolt Holes | 23 in. |
| Net Weight | 11.46 lb. |
| Cross References | 16-16749-000, 1616749000, 345-213, 345213, 681-326-6316, 6813266316, E-8808, E8808, GAFF11153, R308808, TMR515 |
| Intended Application | - Compatible with Freightliner trucks equipped with the Air Ride air suspension system, corresponding to the FAS II configuration.
- Always compare with your OEM part number prior to purchase to confirm full compatibility.
|
| BOM | - Torque Rod pcs x 1
- Torque Rod Bush pcs x 2
|
