| Product Line | Electrical |
| Category Name | Switches & Flashers |
| Part Type | Reverse Switch |
| Alternate Part Name | Brake Light Switch, Back Up Light Switch, Precision Ball Switch |
| OEM Part Number | 1MR2297 |
| Application Type | Heavy Duty Trucks, Semi-Trucks |
| Terminal Connection Type | Stud |
| Terminals Count | 2 |
| Material | Galvanized Steel |
| Across the Flats (AF) | 7/8 in. |
| Thread Size | 9/16-18 UNF |
| Current Rating | 5:00 AM |
| Operating Temperature Range | -40 Deg. C - 120 Deg. C |
| Operating Voltage | 12 - 24 Volts |
| Switch Operation Type | Precision Ball Switch |
| Cross References | 1MR2297, 22940, 454925C1, MSW-4396, MSW4396 |
| Intended Application | - Compatible with the entire Fuller 11609 series and Fuller 6613 transmissions, as well as a wide variety of Navistar Universal applications. Within the Mack line, its design is compatible with the Universal standard, functioning precisely in specialized models such as the 20-speed TRQ-7220 transmission, the 5-speed TRL-107 and TRL-1076/1078 series, and the 6-speed TRDXL-107. It is also fully compatible with the 10- and 7-speed TRDL/TRDLG-107 and 1070 series transmissions.
- Always compare with your OEM part number prior to purchase to confirm full compatibility.
|
