| Product Line | Steering Components |
| Category Name | Power Steering Pump |
| Part Type | Steering Pump |
| Alternate Part Name | Hydraulic Power Steering Pump |
| OEM Part Number | 1686649C91 |
| Application Type | Semi-Trucks, Heavy Duty Trucks |
| Inlet Port Thread Size | 1-1/16-12 UN |
| Mounting Type | 2 Bolt Flange SAE-A SIZE |
| Outlet Port Thread Size | 3/4-16 UNF |
| Material | Iron |
| Max Operating Speed | 3600 rpm |
| Max Relief Pressure | 165 bar |
| Nominal Flow Rate | 16.0 L/min |
| Pump Displacement | 21.0 cm³/rev |
| Shaft Rotation Direction | Left-Hand |
| Package Length | 7.00 in. |
| Package Width | 7.00 lb. |
| Package Height | 7.00 in. |
| Net Weight | 7.48 lb. |
| Cross References | 1686649C91, 451432E, 542 0273 10, 542027310 |
| Intended Application | Compatible with International Navistar DT360 / DT466 Engines. |
