| Product Line | Suspension |
| Category Name | Air Springs and Bags |
| Part Type | Rolling Lobe Air Spring |
| Alternate Part Name | Air Suspension Bag, Reversible Sleeve Air Spring, Rolling Lobe Air Spring, Air Ride Spring, Pneumatic Spring, Suspension Air Bag, Air Bag Suspension |
| OEM Part Number | W01-358-9875 |
| Application Type | Semi-Trucks, Heavy Duty Trucks |
| VMRS Code | 016-008-000 |
| Material | Fiber reinforced rubber bellows |
| Air Inlet Inside Thread | 1/4-18 NPT |
| Air Inlet Outside Thread | 3/4 16 UNF |
| Body Diameter | 10.00 in. |
| Bottom Plate Alignment | Parallel |
| Bottom Plate Diameter | 10.00 in. |
| Bottom Plate Stud | 1/2-13 UNC |
| Mounting Stud Configuration - Bottom | 1 |
| Mounting Stud Configuration - Top | 2 |
| Piston Height | 4.65 in. |
| Piston Material Type | Composite |
| Top Plate Diameter | 9.00 in. |
| Top Plate Stud | 3/4-10 UNC |
| Air Spring Type | 1T Reversible Sleeve |
| Collapsed Length | 6.70 in. |
| Extended Length | 23.00 in. |
| Net Weight | 13.04 lb. |
| Cross References | 1R12-432, 1R121077, 1R12432, 3521191, 3541731C1, 566CT73746, 73746, 910S18P1067(BK), AB1DF23IP1067, FAS-0729, FAS0729, FS1191, FS9875, W01-358-1191, W01-358-9875, W013581191, W013589875, 910S18P1067 |
| Intended Application | - Compatible with International/Navistar Trucks equipped with Bead Plate Bracket (Single Hole) Suspension Mounting
|
